| Brand：SANKEN Model：SKHS-2030，SKHS-2540，SKHS-2560 Name：Tempering Glass Heat Soak Test Furnace
|
Equipment introduction：
Tempered glass homogenizing furnace is the testing equipment for the finished product of tempered glass. After the glass tempering process is completed, it enters the homogenizing furnace. The hot-dip principle of the homogenizing furnace is used to perform the detonation test and eliminate the residual nickel sulfide. The tempered glass with uneven internal stress is detonated in advance during the test process, thereby avoiding "self-explosion" after the installation of the tempered glass, and the qualified rate of the tempered glass after homogenization will be greatly improved, thereby improving the safety of the tempered glass of the building. Reliability
Device parameters:
Code No | Max. Processing Glass Size | Max. Processing Glass Thickness | Furnace Inner Size | Heating time | Productivity | Dimension of Equipment |
SKHS-2560 | 2500 x 6000mm | 2-25mm | 6800 x 1920 x3020mm | 2~4hour
| 7000KG/Cycle | 7300 x 3160 x 4100mm
|
Device application:
Testing equipment for tempered glass finished products to improve the safety and reliability of tempered glass
